MIO-HDMI/DVI-HDSDI is a miniature high quality video converter, which converts an HDMI/DVI-D signal into an HD/SD-SDI video. It is very useful in studios and TV stations where you usually need to use signals from the PC display adapter for broadcasting or editing on non-linear workstations. Not only is it a signal converter, it is also a video and audio quality survey and alarm indicator. It supports 4:3, 16:9 and full screen display mode. The signal’s UMD, Tally and VU indicator position can be configured freely. It fully supports WEBSERVER and SNMP protocols, by which configuration and operation can be done conveniently.

Application



Specification

Video Input: Video Output:
Connector: 1xHDMI Connector: 1xBNC 75Ω　
Video Resolution:
   800x600x75p      1024x768x60p
   1280x772x60p     1280x768x50p
   1366x768x60p     1920x1080p50
   1920x1080p60 		 Video Format:
   SD: 576i50, 480i59.94
   HD: 525i, 625i,720p
         1080i 50/59.94/60
        1080p23.98/25/29.97/30
External Control: Size:
1 x RJ45, 10M/100M Adaptive 4.8" x 3.9" x 1.1"    (120x98x27mm)
Power:  +12V    1.8 A　

Key Features

  • Fully support 1080P
  • SD-SDI and HD-SDI auto sensing
  • Embedded audio support
  • Advanced video de-interlacing processing
  • Video and audio signal auto survey by programmable threshold
  • Flexible alarm indicators, such as video/audio lost, frozen, black video, EDH error, mute
  • Programmable UMD characters
  • Four channel VU meters indication
  • Tally signal support
  • Built-in Web server and SNMP protocol
  • 4:3,16:9 and full screen display modes support
  • Apple HD Cinema Display compatible
  • HDMI V1.3 compatible
  • Dolby 5.1 compatible
  • CEA timing standards compliant
Download Specification

Other products

MVS Series
VIO Series
MIO Series
MRS Series
XIO Series
Control Menu
MIO-HDSDI-HDMI/DVI-menu　
Flexible Display Selection
MIO-HDSDI-HDMI/DVI display Mode
